Feed size: ≤ 800mm
Capacity: 60-2000t/h
The CI impact crusher employs optimized manufacturing technology and a special structural design, producing cubical finished products free of tension and cracks, with excellent particle shape.
Its discharge particle size is adjustable, allowing for diverse crushing specifications.
The impact crusher's material crushing fully meets the requirements of the new "more crushing, less grinding" process.
Capable of processing over 200 different types of materials, with strong adaptability to various mining,construction, and industrial processing scenarios.
The uniquely shaped hammer and robust locking structure provide excellent impact and wear resistance while maintaining stable discharge particle size. The hammer can be replaced vertically and horizontally to adapt to different site requirements.
Modular design allows for the interchangeability of most wear parts, effectively reducing wear parts consumption, extending replacement cycles, reducing spare parts inventory, and saving costs.
The hydraulic opening and discharge port adjustment device (with automatic overload protection) allows for rapid replacement of wear parts, control of discharge particle size and gradation, achieving high adjustment accuracy and speed, reducing labor intensity and downtime.
Optimized frame structure results in higher connection strength, lighter weight, and a compact structure, facilitating installation, maintenance, and transportation.
Global coverage, consistent quality, trusted by customers worldwide.
| Model | Maximum Feeding Size (mm) | Power (kw) | Capacity (t/h) | Dimensions(L×W×H)(mm) |
| CI1110 | 250 | 160 | 60-210 | 2826×2087×2285 |
| CI1213 | 300 | 200 | 80-280 | 2903×2530×2411 |
| CI1316 | 300 | 250 | 100-350 | 3320×2770×2535 |
| Cl1321 | 300 | 315 | 130-430 | 2955×3285×2585 |
| Cl1521 | 350 | 2×(200-250) | 200-600 | 3450×3620×2770 |
| Cl1524 | 350 | 2×315 | 240-700 | 3450×3925×2855 |
| Cl1630 | 400 | 710-800 | 300-900 | 3693×4520×3173 |
| Model | Maximum Feeding Size (mm) | Power (kw) | Capacity (t/h) | Dimensions(L×W×H)(mm) |
| CI1313 | 600 | 200 | 100-480 | 2972×2560×2937 |
| CI1415 | 600 | 250 | 120-600 | 2985×2790×3068 |
| CI1620 | 800 | 2×(200-250) | 220-900 | 4261×3480×3780 |
| CI2023 | 800 | 2×500 | 400-2000 | 5151×4424×4712 |
| Model | Maximum Feeding Size (mm) | Capacity(t/h) |
| CI1110 | 250 | 60-210 |
| CI1213 | 300 | 80-280 |
| CI1316 | 300 | 100-350 |
| Cl1321 | 300 | 130-430 |
| Cl1521 | 350 | 200-600 |
| Cl1524 | 350 | 240-700 |
| Cl1630 | 400 | 300-900 |
| Model | Maximum Feeding Size (mm) | Capacity(t/h) |
| CI1313 | 600 | 100-480 |
| CI1415 | 600 | 120-600 |
| CI1620 | 800 | 220-900 |
| CI2023 | 800 | 200-2000 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
