Sand pump power: 11-55kw
Water processing capacity: 30-650m³/h
The fine sand recovery machine uses a slurry pump to inject mud with a concentration ≤40% into a hydrocyclone separator for separation.
The separated coarse particles are then dewatered and recovered via a dewatering screen.
This process maximizes the recovery of materials larger than 0.075mm while removing sludge and clay smaller than 0.075mm.
It can be used in conjunction with existing sand washing machines on production lines or independently to improve resource utilization and maximize profits.
The separated coarse particles are then dewatered and recovered via a dewatering screen.
This process maximizes the recovery of materials larger than 0.075mm while removing sludge and clay smaller than 0.075mm.
Combines dewatering and fine sand recovery functions
The hydrocyclone is lined with high-quality polyurethane screen plates, providing impact and wear resistance
Employs an energy-saving vibrating motor with an integrated design between the motor and eccentric block, making use and maintenance more convenient and efficient
| Model | Sand Pump Power (kw) |
Sepatator Spec (mm) |
Dewatering Screen | Processing Water Volume (m3/h) |
|
| Specifications (mm) |
Power (kw) |
||||
| HX-250 | 11 | 250 | 800×2000 | 2×0.75 | 30-60 |
| HX-300 | 15 | 300 | 800×2000 | 2×0.75 | 60-100 |
| HX-350 | 18.5 | 350 | 1000×2000 | 2×1.52 | 70-130 |
| HX-550 | 11×2 | 250×2 | 1200×3000 | 2×2.4 | 100-220 |
| HX-650 | 15×2 | 300×2 | 1500×3000 | 2×3 | 120-272 |
| HX-750 | 18.5×2 | 350×2 | 1500×3000 | 2×3 | 180-350 |
| HX-750(Ⅱ) | 22×2 | 350×2 | 1800×3600 | 2×3.7 | 230-430 |
| HX-900 | 18.5×3 | 350×3 | 1800×3600 | 2×3.7 | 450-650 |
| Model | Sand Pump Power (kw) |
Processing Water Volume (m3/h) |
| HX-250 | 11 | 30-60 |
| HX-300 | 15 | 60-100 |
| HX-350 | 18.5 | 70-130 |
| HX-550 | 11×2 | 100-220 |
| HX-650 | 15×2 | 120-272 |
| HX-750 | 18.5×2 | 180-350 |
| HX-750(Ⅱ) | 22×2 | 230-430 |
| HX-900 | 18.5×3 | 450-650 |
