Feed size: ≤215mm
Capacity: 36-650t/h
The GYS cone crusher is based on the PSG spring cone crusher technology and adopts advanced automated control design concepts. It inherits the reliable structure and low failure rate of the traditional PSG series cone crushers, reducing downtime and lowering the labor intensity of workers.
Capable of processing over 200 different types of materials, with strong adaptability to various mining,construction, and industrial processing scenarios.
Utilizes a safety cylinder for automatic control of overload protection and clearing functions.
Easily achieves remote and local control.
Compact size, uses aviation connectors for electrical connections, no wiring required.
Discharge port is adjusted via a hydraulically driven cylinder for easy adjustment.
Dust collection components use dry grease seals, ensuring reliable structure and low failure rate.
Steel frame base structure reduces foundation requirements and lowers foundation investment.
| Model | Cavities | Broken cone big end diameter（mm） | Feeding Size（mm） | Max.feeding Size（mm） | Adjusting Range of Discharge Opening（mm） | Processing capacity（t/h） | Power（kw） |
| GYS 300 | C1 | 910 | 175 | 140 | 13-38 | 81-180 | 90 |
| C2 | 102 | 80 | 9-22 | 60-180 | |||
| F1 | 76 | 60 | 3-16 | 36-145 | |||
| F2 | 41 | 30 | 3-13 | 36-130 | |||
| GYS 400 | C1 | 1300 | 241 | 190 | 19-51 | 207-400 | 200 |
| C2 | 210 | 168 | 16-38 | 162-350 | |||
| C3 | 137 | 110 | 13-31 | 126-310 | |||
| F1 | 105 | 85 | 8-25 | 109-230 | |||
| F2 | 89 | 70 | 6-16 | 82-230 | |||
| F3 | 64 | 50 | 3-16 | 40-230 | |||
| GYS 500 | C1 | 1600 | 269 | 215 | 25-64 | 280-650 | 280 |
| C2 | 241 | 190 | 22-51 | 258-450 | |||
| C3 | 209 | 170 | 16-38 | 180-410 | |||
| F1 | 133 | 105 | 10-25 | 162-355 | |||
| F2 | 89 | 70 | 6-19 | 136-330 | |||
| F3 | 70 | 55 | 5-13 | 90-300 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
| Model | Cavities | Max.feeding Size（mm） | Processing capacity（t/h） |
| GYS 300 | C1 | 140 | 81-180 |
| C2 | 80 | 60-180 | |
| F1 | 60 | 36-145 | |
| F2 | 30 | 36-130 | |
| GYS 400 | C1 | 190 | 207-400 |
| C2 | 168 | 162-350 | |
| C3 | 110 | 126-310 | |
| F1 | 85 | 109-230 | |
| F2 | 70 | 82-230 | |
| F3 | 50 | 40-230 | |
| GYS 500 | C1 | 215 | 280-650 |
| C2 | 190 | 258-450 | |
| C3 | 170 | 180-410 | |
| F1 | 105 | 162-355 | |
| F2 | 70 | 136-330 | |
| F3 | 55 | 90-300 |
Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
