Feed size: ≤55mm
Capacity: 260-703t/h
The VSI7A series impact crusher is a new type of deep-cavity sand making and shaping equipment designed based on industry conditions, working conditions, and user needs.
It features a novel structure, high output, intelligent operation, and environmental friendliness.
Its optimized material impact angle design in the crushing chamber allows it to process various types of stones into sand of different particle sizes, providing high-quality sand and gravel aggregates.
Capable of processing over 200 different types of materials, with strong adaptability to various mining,construction, and industrial processing scenarios.
Improves crushing efficiency, increases material throughput, and yields a high finished product rate. It boasts multiple patented technological breakthroughs.
Large discharge port design ensures smooth material flow, effectively preventing material blockage, avoiding abnormal equipment damage, and improving crushing efficiency.
Equipped with a hydraulic cover opening device for convenient maintenance; the lifting device can be equipped with a manual or electric hoist, easily lifting the feed hopper, lifting plate, impeller, bearing chamber, etc., during equipment inspection and maintenance.
The adoption of new processes and materials greatly extends the life of wear parts, effectively reducing downtime for maintenance and wear.
Global coverage, consistent quality, trusted by customers worldwide.
| Model | Hard material | Soft material | Sand Making | Sand Shaping | Motor Power（kw） |
| Max.Feeding Size （mm） | Throughput（t/h） | ||||
| VSI7A 400 | <45 | <55 | 260-285 | 314-345 | 2×200 |
| VSI7A 500 | <45 | <55 | 345-370 | 412-578 | 2×250 |
| VSI7A 630 | <50 | <60 | 455-488 | 544-760 | 2×315 |
| VSI7A 710 | <50 | <60 | 508-560 | 610-860 | 2×355 |
| VSI7A 800 | <50 | <60 | 600-645 | 722-1005 | 2×400 |
| VSI7A 1000 | <50 | <60 | 780-843 | 940-1310 | 2×1000 |
Note:Processing Capacity May Vary With Different Materials And Feeding Sizes.
| Model | Sand Making | Sand Shaping | Motor Power（kw） |
| Throughput （t/h） | |||
| VSI7A 400 | 260-285 | 314-345 | 2×200 |
| VSI7A 500 | 345-370 | 412-578 | 2×250 |
| VSI7A 630 | 455-488 | 544-760 | 2×315 |
| VSI7A 710 | 508-560 | 610-860 | 2×355 |
| VSI7A 800 | 600-645 | 722-1005 | 2×400 |
| VSI7A 1000 | 780-843 | 940-1310 | 2×1000 |
Note:Processing Capacity May Vary With Different Materials And Feeding Sizes.
